HMYQJF12T
| Model | HMYQJF12T |
| Chassis model | FAW Jiefang National VI Special Chassis |
| Maximum lifting capacity | 12000kg |
| Boom type | 7.3m, 5 sections, single-board arm, internal rope walking |
| Maximum lifting height | 31.5m |
| Outrigger span (horizontal * vertical) | 6400*5000 |
| Overall dimensions | 10380*2380*3330 |
| Motor power | 15kw |
| Hydraulic system | Hydraulic Dual-pump Confluence System |
| Rotation speed | 0-3rap |
| Engine model | Engine Model: Weichai National VI |
| Engine power | 140kw |
| Tire model | 900R20 steel-belted tire |
| Reducer model | Planetary Gear Reducer |
| Slewing support | Internal rope walking: 1.4 meters |
| Main frame structure | Large box-type frame |
| Steering mode | Hydraulic power assist |
| Brake type | Air brake |
| Transmission | Fast 8-speed gearbox (Fashite) |
| Weight | 16000kg |
| Driver’s cabin | XCMG driver’s cabin |
| Emission standard | National VI |
| Wheelbase | 4200 |
| Main hoist winch | 12-ton winch |
| Auxiliary hoist winch | 12-ton winch |
| Travel speed | 90km/h |
